Zone Offroad 5" Lift Kit with Radius Arms for 2023+ Ford F250/F350
Zone Offroad 5" Lift Kit with Radius Arms for 2023+ Ford F250/F350
Zone Offroad 5" Lift Kit with Radius Arms for 2023+ Ford F250/F350
Zone Offroad 5" Lift Kit with Radius Arms for 2023+ Ford F250/F350

Zone Offroad 5" Lift Kit with Radius Arms for 2023+ Ford F250/F350

Vendor: Zone Offroad
Product Type: 5" Lift Kit
SKU: ZONF123
Stock: Checking...
$3,100.00
$3,100.00
Please hurry! Only 0 left in stock
Shocks: No Shocks
OVERVIEW

Zone Offroad now offers 5" radius arm lift kits for the 2023-2025 Ford F250/F350 Super Duty 4WD diesel trucks. These new 5" lift kits are designed to be complete with everything needed to properly lift your new Super Duty to allow clearance for up to 37" tires. As with all Zone lift kits, these kits are backed by Factory Protection Plus, the comprehensive extended warranty giving you peace of mind on or off the road with a 5-year, 60,000-mile drivetrain warranty and Zone Offroad's limited lifetime warranty.

SPECIFICATIONS
  • Front Lift Method : Coil Spring & Radius Arm
  • Front Lift Height : 5"
  • Rear Lift Method : Block
  • Rear Lift Height : 3"
  • Shocks Included : Yes
  • Lift Height : 4-5.5"
TYRES & WHEELS

(Trimming may be required)

  • 37 x 12.5 with 20 x 9 and 4.5 in. Backspace
  • 37x12.50 tires may require minor trimming.
  • Factory wheels fit when paired with factory / original equipment tire size.
IMPORTANT NOTES
  1. Two-piece rear drive shaft? Add a carrier bearing drop kit to reduce post-lift driveline angles and avoid / eliminate driveshaft vibration.
  2. When adding the Dual Stabilizer option, you will get the dual opposing steering stabilizer in addition to the single OE Replacement.
  3. Due to taller factory ride height, Tremor models will not net full advertised lift height. Final ride height will be the same as standard models.
  4. Some trucks with a rear drive-line vibration may have a recall from Ford regarding the rear axle. (Safety Recall 21S31) Due to the recall procedure, Zone recommends having this performed prior to installing the lift.
  5. Does not fit vehicles with radius arm mounted ride height sensors.
  6. Fits SRW models only
  7. Recalibration of your vehicles Advanced Driver Assistance System (ADAS) cameras, radars, light detection and ranging (LiDAR), and other sensors may be necessary by your local dealership or ADAS service center. This will ensure proper functionality of the vehicle features such as lane keeping, lane departure, parking assistance, blind-spot detection, adaptive cruise control systems, and other functions as they did prior to installation. Please connect with your local dealership or ADAS service center. Similar to a wheel alignment, all charges and expenses that may occur from dealership calibrations and adjustments are the sole responsibility of the vehicle owner.
INSTALLATION
  • Installation Guides : Download Guide
  • Est. Install Time : 4-6 hrs
  • Difficulty Level : Difficult
  • Tools Needed : 30mm Socket, 46mm Socket, Hydraulic Floor Jack and Jack Stands, Pitman Arm Puller
Features & Benefits
FITMENT
