Chev Silverado 1500 / 2500 High Beam Patch Harness

Designed to suit both the 2019+ Chevrolet Silverado 1500 and 2024+ Chevrolet Silverado 2500, this High Beam Patch Harness provides a simple and convenient solution for integrating your aftermarket lighting.

Featuring dedicated 3-pin Deutsch connectors for each vehicle model, along with a universal high beam trigger connection, this harness makes connecting your auxiliary lighting and DRL functions easier.

High Beam Trigger Connection

The harness includes a universal high beam trigger connection that works with both the Silverado 1500 and 2500.

  • Blue Wire: High beam trigger signal.

  • Black Wire: Negative terminal, used for certain DRL functions on compatible lights (commonly found on STEDI lighting).

The high beam trigger features a plug commonly found on many aftermarket wiring harnesses. If the supplied plug does not match your wiring harness, simply cut the connector off and join the corresponding wires together.

3-Pin Deutsch Connectors

The harness includes two separate 3-pin Deutsch connectors, clearly labelled for each vehicle model.

Chevrolet Silverado 1500 Connector (2019+)

  • Red Wire: Indicator

  • Yellow Wire: Parkers / DRL

  • Black Wire: Earth

Chevrolet Silverado 2500 Connector (2024+)

  • Brown Wire: Parkers / DRL

  • Green Wire: Indicator

  • Black Wire: Earth

Key Features

  • Compatible with 2019+ Chevrolet Silverado 1500.

  • Compatible with 2024+ Chevrolet Silverado 2500.

  • Universal high beam trigger connection for both models.

  • Dedicated 3-pin Deutsch connectors for each vehicle.

  • Provides indicator, parker/DRL and earth connections.

  • Compatible with a wide range of aftermarket lighting setups.

Important: Ensure you connect to the Deutsch plug labelled for your specific vehicle model. Check all wiring connections before powering up your lights.





  • Twin Plug for High Beam Trigger + Earth (connects to most brands of lights, with the Earth allowing for DRL use on Spot Lights / Light Bars)
  • Blue Wire is the High Beam Trigger, Black Wire is the Earth

Chevrolet Silverado 1500 Connector (2019+)

  • Red Wire: Indicator
  • Yellow Wire: Parkers / DRL
  • Black Wire: Earth

Chevrolet Silverado 2500 Connector (2024+)

  • Brown Wire: Parkers / DRL
  • Green Wire: Indicator
  • Black Wire: Earth
  • This harness is not compatible with vehicles fitted with the 8-pin headlight connector.
